| Physical Characteristics |
| Dimensions: |
2.4 in. H x 7.1 in. L x 2.4 in. W
(6.2 cm H x 18 cm L x 6 cm W) |
| Weight: |
Approximately 4.3 oz. (122 g) |
| Voltage & Current: |
5 +/-10%VDC @ 100 mA (Stand by: <35 mA) |
| Power Source: |
Host power or external power supply |
| Color: |
Cash Register White or Twilight Black |
| Performance Characteristics |
| Scanner Type: |
Bi-directional |
| Light Source (Laser): |
650nm laser diode |
| Scan Rate: |
100 scans per second |
| Typical Working Distance: |
From contact to 8 in./20.32 cm on 100% UPC/EAN symbols |
| Print Contrast Minimum: |
30% minimum reflectance |
| Roll (Tilt):1 |
± 30° from normal |
| Pitch:2 |
± 65° |
| Skew (Yaw):3 |
± 60° |
| Decode Capability: |
UPC/EAN, UPC/EAN with Supplementals, UCC/EAN 128, Code 39, Code 39 Full ASCII, Code 39 TriOptic, Code 128, Code 128 Full ASCII, Codabar, Interleaved 2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11, IATA, RSS variants, Chinese 2 of 5 |
| Interfaces Supported: |
RS-232; Keyboard Wedge; USB |
| User Environment |
| Operating Temperature: |
32° to 122° F/0° to 50° C |
| Storage Temperature: |
-40° to 158° F/-40° to 70° C |
| Humidity: |
5% to 95% relative humidity, non-condensing |
| Drop Specifications: |
Withstands multiple 5 ft./1.524m drops to concrete |
| Ambient Light Immunity: |
Immune to direct exposure of normal office and factory lighting conditions, as well as direct exposure to sunlight |
| Beeper Volume: |
User-selectable: three levels |
| Beeper Tone: |
User-selectable: three tones |
| Electrostatic Discharge: |
Conforms to 15 kV air discharge and 8 kV of contact discharge |
| Regulatory |
| Electrical Safety: |
UL1950, CSA C22.2 No. 950, EN60950/IEC950 |
| EMI/RFI: |
FCC Part 15 Class B, ICES-003 Class B, European Union EMC Directive, Australian SMA, Taiwan EMC, Japan VCCI/MITI/Dentori |
| Laser Safety |
IEC Class 1 |
